Product Details
＋
Specifications
| 01. FRAME | All New, Series 4 Alloy, 160mm MultiTrac Suspension LT, Adjustable Headset & CS Length/Height, Integrated Battery/Charging Port, 148mm Rear Thru-Axle |
| 02. FRONT SUSPENSION | Fox 38 Performance Elite, 170mm Travel, 29" , 110xl 5mm Boost Kabolt Thru-Axle, 44mm Offset, Integrated Fox Fender |
| 03. REAR SUSPENSION | Fox DHX2, Performance Elite, Low Speed Compression and Rebound Adjustment, 205x65mm, Trunnion Upper Mount, 30mmxM8 Lower Mount, S/M Spring Rate= 350Ib, L/XL Spring Rate= 450Ib |
| 04. RIM | Front: 29" Diameter, 32mm Inner Rim Width; Rear: 27.5" Diameter, 32mm Inner Rim Width, Tubeless Compatible |
| 05. HUB REAR | Shimano HB-TC500, 148x12mm, Centerlock, Standard Freehub Body |
| 06. HUB FRONT | Shimano FH-TC500, 11 0xl 5mm, Centerlock, 32H |
| 07. SPOKES | 14g Black Stainless Steel |
| 08. TIRES | Vee Tire Co Attack HPL, E-Control Compound, Front 29x2.5", Rear 27.5x2.5" |
| 09. DERAILLEUR REAR | Shimano XT 12-Speed, SGS |
| 10. DERAILLEUR FRONT | 0 |
| 11. SHIFT LEVER | Shimano SLX 12-Speed, I-Spec EV |
| 12. CRANKSET | e*thirteen e*spec Plus Cranks, 160mm Length |
| 13. MOTOR | Bosch Performance CX, 85Nm |
| 14. CHAIN | KMC El 2S, E-Bike Specific Chain |
| 15. CASSETTE | Shimano SLX M7100 Cassette, 12-Speed, 10-51T |
| 16. BRAKES FRONT | TRP DH-R EVO 4-Piston Hydraulic Disc, 203mm, 2.3mm Thick |
| 17. BRAKES REAR | TRP DH-R EVO 4-Piston Hydraulic Disc, 203mm, 2.3mm Thick |
| 18. BRAKE LEVERS | TRP DH-R EVO Hydraulic |
| 19. HANDLEBAR | Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back |
| 20. STEM | Marin CNC, 35mm Length, 35mm Bar Bore |
| 21. GRIPS | Marin Grizzly Lock On |
| 22. HEADSET | FSA Custom Headset, Adjustable HTA Design |
| 23. SEATPOST | TranzX, YSP39 1 x Remote, 34.9 Seatpost Diameter, Travel S = 150mm, M/L = 170mm, XL = 200mm |
| 24. SADDLE | Marin Speed Concept |
| 25. PEDALS | 0 |
| 26. BATTERY | Bosch PowerTube 750 Wh |
| 27. DISPLAY | Bosch BRC3100 Systems Controller |
| 28. SWITCH | Bosch BRC3300 Bluetooth Remote 22.2mm Clamp |
| 29. EXTRAS | e*thirteen e*Spec Chainguide |
| 30. EXTRAS | Cush Core Pro Tire Inserts, Marin Tire Sealant 300ml Bottle |
