Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Backlighting | Backlight |
| Communication | Major PLC's |
| Current Consumption | 25 A |
| Current Rating | 30 A |
| Depth | 1.839" (46.7mm) |
| Dimensions | 257.5 x 199.5 x 46.7 mm |
| Display Colors | Color |
| Display Resolution | 800 x 600 Pixels |
| Display Size | 10.4 Inch Display |
| HMI Type | Touch Screen HMI |
| Length | 10.138" (257.5mm) |
| Maximum Operating Temperature | 50 C |
| Minimum Operating Temperature | 0 C |
| Mounting Type | Chassis Mount |
| Number of Ports | 9 Port |
| Port Style | RS232, RS485, RS422, RJ45, USB Port |
| Primary Type | Operator Interface |
| Resolution, Display | 800 x 600 |
| Series | |
| Special Features | Remote Access ; Expansion I/O |
| Supply Voltage | 24VDC |
| Technology | TFT LCD Display |
| Temperature Operating Range | 0 to 50 C |
| Type | Color Graphic |
| Voltage Rating | 24 VDC |
| Width | 7.854" (199.5mm) |
